Specifications
|
Color: Black
Material: Steel
CID: 2.7
Action: Double Acting
Mounting Holes: 4x0.3"
Max Pressure: 3600 PSI
Working Port: 3/8" NPTF
Piston Action: Double Function
Tank: 3-quart Steel Vertical Tank
Reservoir Capacity: 0.75 gal (3 qt)
Lever: 21" Steel Handle Included
Durable Cast Iron Monoblock Body
|
|
Features
① Piston-Type Dual-Function Mode: Piston-type dual-function operation enables hydraulic power output for both push and pull strokes, ensuring efficient utilization of handle operation. Enhances efficiency by increasing fluid flow velocity and smoothness.
② Superior Performance: This device generates pressures up to 3600 PSI, suitable for lifting, clamping, testing, and hydraulic tool operation.
③ Convenient and Quick: Manual operation requires no power source, ideal for remote locations, field repairs, and backup systems.
④ Durable and Long-lasting: Featuring an integrated cast iron pump body, this hydraulic hand pump converts manual force into hydraulic energy. Suitable for single/double-acting systems, it delivers reliable outdoor performance.
⑤ Versatile Applications: Provides stable fluid pressure when electric or pneumatic sources are unavailable. Compact and portable, it serves emergency rescue, field operations, and auxiliary power needs.
